Product introduction
Short description
The IJW9000 uses the Konica Minolta 1024i industrial printhead to deliver a nominal print width of 72 mm at 360 dpi per head. Its modular 1–24 printhead architecture supports detailed variable data, wider stitched images, multiple print lanes, and project-specific UV printing equipment.
Product overview
The IJW9000 is built for industrial printing projects that need useful single-head coverage, 360 dpi nominal resolution, and a clear path to wider formats. It can print fixed and variable text, barcodes, QR codes, serial numbers, graphics, logos, and database-driven content on validated materials.
A one-head system provides a nominal 72 mm print area. Multi-head configurations can extend the printable span, support multiple products in parallel, or create independent print zones. From 1 to 24 Konica Minolta 1024i printheads may be configured within the platform according to the print layout and production design.
The final IJW9000 system may include material transport, UV LED curing, data processing, sensing, encoding, inspection, and external control functions. These elements are selected after the application has been evaluated.
Printhead configuration
- Printhead brand and series: Konica Minolta 1024i
- Nominal print width per printhead: 72 mm
- Nominal resolution: 360 dpi
- Configurable printheads: 1–24
- Nominal combined coverage: 72–1,728 mm before stitching overlap
- Configuration options: single zone, stitched wide image, multiple lanes, or customized print positions
Key features
- Konica Minolta 1024i industrial printhead platform
- 72 mm nominal print width per head
- 360 dpi nominal resolution
- Flexible configuration from 1 to 24 printheads
- Fixed and variable-data printing
- Expandable coverage for wide and multi-lane applications
- UV LED curing matched to the selected process
- Supports production-line sensing and synchronization
- Optional database, traceability, and inspection integration
Typical print content
- QR codes, DataMatrix codes, and barcodes
- Serial numbers and unique product codes
- Dates, batches, lots, and manufacturing information
- Product text and specifications
- Logos, graphics, and symbols
- Variable promotional or security data
- Database-generated content
Suitable applications
- Packaging, labels, and flexible packaging
- Cards, vouchers, tickets, and security printing
- Pharmaceutical and medical packaging
- Consumer-product and cosmetics packaging
- Electronics and industrial components
- Industrial products and selected building materials
- Wide or multi-lane variable-data printing
Materials
Typical evaluation materials may include coated paper, synthetic paper, labels, cards, suitable plastics, films, foils, boards, and industrial surfaces. Actual print performance depends on the selected UV ink, substrate condition, curing energy, print speed, and resistance requirement.
Integration and automation
The IJW9000 can be engineered for feeders, conveyors, web handling, sheet transport, sensors, encoders, databases, UV LED curing, inspection cameras, and rejection systems. Multi-head projects require confirmed mechanical tolerances, image stitching, synchronized data, and a matched curing arrangement.
Specification snapshot
| Item | IJW9000 specification |
|---|---|
| Printing technology | Piezoelectric drop-on-demand UV inkjet |
| Printhead | Konica Minolta 1024i industrial printhead |
| Nominal width per printhead | 72 mm |
| Nominal resolution | 360 dpi |
| Printhead quantity | 1–24, configurable |
| Nominal combined coverage | Up to 1,728 mm with 24 heads, before overlap |
| Ink process | UV-curable ink with matched UV LED curing |
| Print content | Fixed and variable text, codes, numbers, barcodes, and graphics |
| Operating format | Standalone or inline integration |
| Final performance | Confirm according to the engineered configuration |
Why choose the IJW9000
Choose the IJW9000 when the application requires a 72 mm single-head print width, 360 dpi nominal resolution, and modular expansion for a wider or multi-lane production layout. It is suitable for integrators and industrial users building a UV printing system around the Konica Minolta 1024i platform.
Call to action
Share your total print width, number of lanes, product movement, print content, and material. Inkjetwell will recommend the printhead count, system layout, UV curing configuration, and validation plan.
Primary CTA: Configure the IJW9000
Secondary CTA: Request Sample Printing
