Product introduction
Short description
The IJW6000 is a high-resolution UV inkjet platform available with a Ricoh G5 or Ricoh G6 industrial printhead. Each printhead provides a nominal print width of 54.18 mm at 600 dpi. Systems can be configured with 1 to 24 printheads for detailed variable data, wider stitched images, and multi-lane production.
Product overview
The IJW6000 is designed for applications where fine text, detailed codes, image definition, and data accuracy are important. Its 600 dpi nominal resolution supports high-quality QR codes, DataMatrix codes, barcodes, serial numbers, graphics, and database-driven content on verified substrates.
Customers can select a Ricoh G5 or Ricoh G6 printhead configuration according to the final engineering requirement. Both choices belong to the same IJW6000 base platform. A single printhead offers a nominal 54.18 mm print width, while a multi-head configuration expands the printable area or provides several synchronized print zones.
From a one-head coding station to a 24-head project platform, the printhead layout, controller, data workflow, material transport, UV curing, and inspection functions are designed around the production process.
Printhead configuration
- Printhead brand and series: Ricoh G5 or Ricoh G6
- Nominal print width per printhead: 54.18 mm
- Nominal resolution: 600 dpi
- Configurable printheads: 1–24
- Nominal combined coverage: 54.18–1,300.32 mm before stitching overlap
- Configuration options: single image, stitched wide image, multiple lanes, multiple positions, or project-specific arrangement
Key features
- Choice of Ricoh G5 or Ricoh G6 industrial printhead
- 54.18 mm nominal width per printhead
- 600 dpi nominal resolution for detailed codes and graphics
- Modular 1–24 printhead configuration
- Fixed, sequential, serialized, and database-driven content
- UV LED curing matched to the selected ink and production speed
- Multi-head stitching and synchronization for wider print areas
- Supports inline transport, sensors, encoders, and external production control
- Can be combined with vision inspection, code verification, and traceability workflows
Typical print content
- High-density QR codes and DataMatrix codes
- One-dimensional and two-dimensional barcodes
- Fine text and small characters
- Serial numbers and unique product identities
- Anti-counterfeit and promotional codes
- Variable graphics, logos, and symbols
- Database records and traceability information
Suitable applications
- Labels and label converting
- Flexible packaging and suitable film
- Cards, tickets, vouchers, and security printing
- Pharmaceutical and medical packaging
- Electronics, PCB-related products, and components
- Cosmetics and consumer-product packaging
- Cartons and coated paper products
- Wide variable-data printing using stitched printheads
Materials
The IJW6000 may be evaluated for coated paper, synthetic paper, labels, plastics, films, cards, foils, and other validated surfaces. Ink adhesion, curing, flexibility, resistance, and post-processing performance are material-dependent and must be confirmed through testing.
Integration and automation
The platform can be connected to product sensors, encoders, databases, external production systems, UV LED curing, vision inspection, rejection devices, feeders, conveyors, and web-handling equipment. The final communication and software scope must be confirmed for each project.
Specification snapshot
| Item | IJW6000 specification |
|---|---|
| Printing technology | Piezoelectric drop-on-demand UV inkjet |
| Printhead | Ricoh G5 or Ricoh G6 industrial printhead |
| Nominal width per printhead | 54.18 mm |
| Nominal resolution | 600 dpi |
| Printhead quantity | 1–24, configurable |
| Nominal combined coverage | Up to 1,300.32 mm with 24 heads, before overlap |
| Ink process | UV-curable ink with matched UV LED curing |
| Print content | Fixed and variable text, codes, numbers, barcodes, and graphics |
| Operating format | Standalone or inline integration |
| Final speed and configuration | Confirm according to printhead choice and application |
Why choose the IJW6000
Choose the IJW6000 when 600 dpi output, detailed variable content, and flexible width expansion are central to the project. The choice of Ricoh G5 or Ricoh G6 printheads allows the system to be engineered for the final production requirement while retaining one consistent product platform.
Call to action
Tell us whether your priority is fine-code quality, print width, production speed, multiple lanes, or database integration. Inkjetwell will evaluate the appropriate Ricoh G5 or G6 configuration and the required number of printheads.
Primary CTA: Configure the IJW6000
Secondary CTA: Request a Print Test
