Product introduction
Short description
The JW8000C is a full-color industrial UV inkjet production line for variable graphics, codes, text, and images. It combines automated feeding, optional plasma treatment, color UV inkjet printing, UV LED curing, and collection in one configurable production workflow.
Product overview
The JW8000C is different from a conventional monochrome coding system. It is designed for customers that require full-color digital printing, variable data, customization, and inline production. The system can process artwork and dynamic data from common image, document, spreadsheet, and text formats.
The referenced platform supports 2–64 configurable printheads, resolution up to 600 dpi, a standard 54 mm print unit, production speed from 0–75 m/min, and material widths from approximately 10–400 mm. Final performance depends on image coverage, color configuration, material, curing, and feeding stability.
The complete process can be configured as:
Feeding → Plasma Treatment → Full-Color UV Inkjet Printing → UV LED Curing → Collection
Key features
- Full-color industrial UV inkjet printing
- Configurable 2–64 printhead architecture
- Resolution up to 600 dpi
- Standard 54 mm print-unit basis
- Referenced production speed of 0–75 m/min
- Referenced material width of approximately 10–400 mm
- Fixed and variable text, barcodes, QR codes, graphics, and images
- BMP, JPEG, PDF, TIFF, Excel, CSV, and TXT data support
- Optional plasma surface treatment
- UV LED curing
- Automated feeding and collection
- Custom production-line integration
Typical print content
- Full-color graphics and images
- Variable QR codes and barcodes
- Personalized text and numbering
- Product designs and decorative information
- Promotional codes
- Security and anti-counterfeit information
- Database-driven color content
Suitable applications
- Labels and flexible packaging
- Cards, tickets, and promotional products
- Cosmetic and premium packaging
- Personalized products
- Short-run and variable-design production
- Industrial digital-printing lines
- Full-color smart packaging
Materials
Typical candidates include coated paper, label stock, cards, selected films, cartons, foil, and suitable flat plastic materials. Plasma treatment can improve adhesion on some low-surface-energy materials, but every production material must be tested.
Integration and automation
The JW8000C can be configured with roll or sheet feeding, tension control, plasma treatment, multiple color channels, UV LED curing, collection, database software, and production controls. Camera inspection and traceability functions can be added according to project requirements.
Specification snapshot
| Item | Draft specification |
|---|---|
| Printing technology | Full-color DOD UV inkjet |
| Printhead count | Configurable, referenced at 2–64 |
| Resolution | Up to 600 dpi |
| Standard print-unit width | 54 mm |
| Referenced speed | 0–75 m/min |
| Referenced material width | Approximately 10–400 mm |
| Data formats | BMP, JPEG, PDF, TIFF, Excel, CSV, TXT |
| Process options | Feeding, plasma treatment, printing, curing, collection |
| Final configuration | Confirm by color, width, speed, and substrate |
Why choose this solution
Choose the JW8000C when the application requires full-color digital output, variable content, and an automated production workflow. It is suitable for customers that need more than monochrome coding and want an integrated inline digital-printing platform.
Call to action
Send us your artwork, material, color requirement, print width, production speed, and finishing process. Inkjetwell will configure the printheads, pretreatment, curing, and material-handling system.
